Exhibition graphics have to do more than look good on a laptop. They need to remain sharp at large sizes, fit the stand structure accurately and arrive at the printer in a format that can be produced without avoidable delays. Small errors in dimensions, image quality, bleed or font handling can lead to blurred graphics, visible white edges or last-minute artwork corrections.
These exhibition stand artwork guidelines explain how to prepare print-ready files for exhibition walls, backdrops, counters, banners and other large-format graphics. Use them as a production checklist, then confirm the final specifications with your exhibition stand contractor or print provider before exporting your artwork.
Quick Overview
- Confirm final artwork dimensions and whether the printer wants files at full size or a scaled size.
- Use a print-ready PDF for many production workflows unless the supplier requests another format.
- Choose resolution based on final output size and viewing distance.
- Add the required bleed and keep important text and logos inside the safe area.
- Confirm colour settings, fonts, linked images and export settings with the production team.
- Request the printer's template whenever one is available.
1. Choose the Right Exhibition Artwork File Format
The best file format depends on the artwork, print process and production provider's workflow. Ask whether the printer needs a press-ready PDF, editable source files or separate image assets.
| File format | Best use | What to check |
|---|---|---|
| Common choice for final print-ready artwork and layouts. | Confirm PDF standard, embedded fonts, image links, colour settings, bleed and page dimensions. | |
| AI | Editable Adobe Illustrator artwork, especially vector logos and illustrations. | Package linked assets and clarify whether a native file or exported PDF is required. |
| EPS | Vector artwork and some legacy production workflows. | Check that the supplier supports EPS in its current workflow. |
| TIFF | High-quality raster images. | Check dimensions, effective resolution, colour mode and file size. |
| PSD | Layered Photoshop source artwork during design and revision. | Confirm whether the printer accepts PSD or requires an exported final file. |
| JPEG | Photographic images and workflows that accept raster artwork. | Use an appropriately high-quality export and avoid undersized source images. |
| SVG | Scalable vector artwork for compatible workflows. | Check font handling, effects and compatibility before treating it as final artwork. |
A properly exported PDF is a practical final-delivery format for many exhibition graphics because it can preserve layout, vector elements and placed images. However, do not assume one PDF preset suits every printer. Follow the supplier's instructions if they specify another format or export profile.
2. Set the Correct Artwork Dimensions
Start with the exact visible panel or graphic dimensions supplied by the stand designer, contractor or print provider. Do not estimate dimensions from a render or use the overall stand size as a substitute for individual graphic panel measurements.
- Work from approved dimensions. Confirm the width and height of each panel, fabric graphic, counter wrap, banner or backwall section.
- Check production scale. Some suppliers request full-size artwork, while others use a stated scale such as 1:2 or 1:10.
- Account for seams and joins. Fabric walls and multi-panel graphics may need overlaps, panel splits or specific allowances.
- Confirm orientation. Check portrait or landscape orientation and ensure artwork is not rotated or mirrored unexpectedly.
- Use the supplier template. Templates can show panel boundaries, joins, finishing areas and parts that may be hidden during installation.
Important: A graphic that is the correct size on screen can still be wrong for production if dimensions exclude bleed, finishing allowances or panel joins. Confirm whether the dimensions provided are the visible finished size or the full artwork size.
3. Understand Resolution for Large Format Printing
Image resolution affects how clearly raster images reproduce in print. Exhibition graphics are often viewed from farther away than brochures, so the ideal resolution depends on final size, viewing distance, image content and printer equipment.
Resolution is commonly described in pixels per inch (PPI) for digital images. Printers may also use dots per inch (DPI) when discussing output devices. These terms are related but are not interchangeable in every technical context.
| Artwork type | Resolution guidance | Practical advice |
|---|---|---|
| Large wall graphics viewed from a distance | May work with lower effective PPI than close-viewed graphics. | Use high-quality source images and ask for the target resolution at final output size. |
| Counter graphics and smaller panels | Often need more detail because visitors can stand close. | Check small text, product photography, fine lines and logos at actual size. |
| Photographs | Depends on pixel dimensions and how large the image is placed. | Check effective resolution after scaling the image in the layout. |
| Logos, icons and illustrations | Vector artwork can scale without the same pixelation limitations as raster images. | Use original vector artwork where possible for logos and crisp line work. |
As a general starting point, some print workflows use around 150 PPI at final size for large-format graphics, while close-viewed work may call for higher resolution. This is not a universal specification. Ask the production provider what effective resolution it recommends for the exact material, output size and viewing distance.
How to Avoid Blurry Exhibition Graphics
- Use original high-resolution images rather than thumbnails downloaded from websites.
- Avoid enlarging small images far beyond their original pixel dimensions.
- Check effective resolution after placing and scaling each image.
- Inspect the exported file, but remember that screen zoom is not a substitute for checking actual dimensions and resolution.
- Keep logos and line illustrations in vector format when possible.
4. Add the Correct Bleed
Bleed is extra artwork that extends beyond the final trim edge. It gives the finishing process room for small cutting or alignment variations and helps prevent an unwanted white edge on the finished graphic.
The required bleed depends on the printer, substrate, finishing method and graphic construction. A bleed of 3 mm is common in many conventional print jobs, but large-format exhibition graphics may require a different amount or a custom template. Never apply a single bleed value to every stand graphic without checking the production specification.
How to Prepare Bleed Correctly
- Confirm the bleed measurement required for the specific graphic.
- Extend background colours, photographs and other edge-to-edge artwork into the bleed area.
- Do not place essential text, logos or critical content in the bleed.
- Include bleed in the exported PDF if requested by the printer.
- Check whether crop marks are required. Add them only when the supplier requests them.
Example: If a supplier specifies a finished panel size of 1,000 × 2,000 mm and requires 10 mm bleed on every edge, the artwork canvas must include that additional area. Confirm how the supplier expects file dimensions and bleed to be set up before preparing the final document.
5. Keep Important Content Inside the Safe Area
The safe area is the region inside the trim or finishing boundary where important content should remain. It protects key elements from being cut off, covered by a frame, hidden by a seam or obscured during installation.
- Keep headlines, body copy, contact details and calls to action comfortably inside the safe area.
- Keep logos away from trim edges, seams, zips, silicone edges and finishing zones.
- Check content near doors, cut-outs, corners, counters and adjoining panels.
- For fabric graphics, ask whether finishing requires extra space around the perimeter.
- Use the contractor's template rather than guessing the safe margin.
Bleed and safe area serve different purposes. Bleed extends artwork beyond the trim edge; the safe area keeps important content away from that edge. A file can have correct bleed and still be unsafe if a headline or logo sits too close to the cut line.
6. Confirm Colour Settings Before Export
Colours can appear different on a backlit screen and on a printed substrate. Screens generally use RGB, while many print workflows use CMYK or a supplier-specific colour-managed process. The correct setup depends on the printer, material, ink system and required brand-colour accuracy.
- Ask before converting. Confirm whether the provider wants CMYK, RGB or a particular ICC profile.
- Check brand colours. Provide approved colour references and ask whether a physical proof or colour test is available.
- Review black settings. Large black areas and small black text may need different settings depending on the print process.
- Check transparency and effects. Gradients, shadows, transparency and overprint settings can behave differently across workflows.
- Do not rely only on your monitor. Screen brightness and calibration can make colours look more vivid than the printed result.
Production tip: Do not convert all artwork to CMYK automatically without checking the printer's instructions. Some large-format workflows prefer RGB files and manage conversion during RIP processing. The print provider's specification should take priority.
7. Prepare Fonts, Logos and Linked Images
Missing fonts, broken links and low-quality logos are common sources of artwork problems. Before delivery, make sure the file contains everything the production team needs to reproduce the approved design.
Fonts
Follow the printer's instructions on embedding fonts in the PDF or converting text to outlines. Outlining can prevent font substitution, but it makes text less editable and can increase file complexity. Keep an editable source file separately where appropriate.
Logos and Vector Elements
Use the approved original logo file whenever possible. Vector artwork is useful for scaling logos and simple illustrations cleanly. If a raster logo must be used, check its effective resolution at the final placed size.
Linked Images
If the printer or designer needs the editable source document, package linked images and other assets using the agreed handover method. If sending only a final PDF, verify that placed images display correctly and are embedded as expected in the export.
8. Export and Check the Final Print-Ready PDF
Exporting a PDF is not the final quality check. Review the file after export and compare it with the approved artwork and the printer's specification.
Preflight Checklist
- Document dimensions match approved production dimensions and scale.
- Bleed is included at the required measurement.
- Crop marks are included only when requested.
- Fonts are embedded or handled as specified by the printer.
- Images have sufficient effective resolution at final size.
- Colour settings and profiles follow the production brief.
- Logos, images and text are not missing, substituted or unexpectedly shifted.
- Important content stays inside the safe area.
- Panel splits, seams, finishing zones and orientation have been checked.
- The PDF opens correctly and has been reviewed after export.
- The file name identifies the project, graphic or panel and revision.
Adobe's guidance on setting bleed for print and creating print-ready PDFs is useful for understanding common prepress checks. Always use your print provider's exact delivery requirements for the final file.
9. Common Exhibition Artwork Mistakes to Avoid
| Common mistake | Why it causes problems | How to prevent it |
|---|---|---|
| Using the wrong dimensions | The graphic may not fit the panel or structure. | Work from approved measurements and the current production template. |
| Forgetting bleed | Finishing variations can expose an unprinted edge. | Confirm required bleed and extend edge-to-edge artwork beyond trim. |
| Putting text too close to edges | Text or logos can be trimmed, covered or hidden by finishing. | Keep critical content within the specified safe area. |
| Using low-resolution images | Photographs and raster logos may look soft or pixelated. | Check effective resolution at final output size and replace poor source images. |
| Assuming every printer wants CMYK | Unrequested conversion can alter the workflow or colour result. | Ask which colour settings and profiles to use. |
| Sending an unverified PDF | Fonts, links, transparency or dimensions may not export as expected. | Open and inspect the exported file and complete a preflight check. |
| Ignoring panel joins | Text, faces or key design elements may cross a seam awkwardly. | Use the panel layout and confirm how graphics will be installed. |
10. Coordinate Artwork With Your Exhibition Stand Contractor
Artwork preparation should happen alongside stand design and production planning, not as a last-minute handover. The stand contractor can confirm graphic dimensions, materials, panel layout, installation method and constraints that affect the artwork.
Before production begins, confirm who is responsible for supplying templates, checking artwork, approving proofs and authorising final print files. If a graphic includes several connected panels, request a layout showing how they will align once installed.
Learn more about exhibition stand design and build. For project-specific requirements, you can also contact the Nucleus Group team to discuss your exhibition brief.
Frequently Asked Questions
What is the best file format for exhibition stand artwork?
A print-ready PDF is commonly used for final artwork, but the right format depends on the production provider. Some suppliers may request AI, EPS, TIFF or another format. Ask for exact file requirements before exporting.
What resolution should exhibition graphics be?
There is no single resolution that suits every exhibition graphic. The required effective PPI depends on final output size, viewing distance, image type and printing process. Ask the print provider for its target resolution at final size.
How much bleed is needed for exhibition printing?
The required bleed varies by printer, material and finishing method. Although 3 mm is common in many conventional print jobs, large-format graphics may require a different allowance. Use the printer's template or written specification.
Should exhibition artwork be in RGB or CMYK?
Follow the print provider's colour workflow. Many print jobs use CMYK, while some large-format workflows accept RGB files and handle conversion during production. Confirm the required colour profile before converting artwork.
Should I outline fonts before sending artwork?
Use the printer's instructions. Embedding fonts in the PDF may be sufficient, while some workflows request outlined text. Keep an editable source file where possible because outlined text is harder to edit.
Can I use a JPEG for exhibition stand graphics?
A JPEG may suit photographic artwork or workflows that accept raster files, provided its pixel dimensions and quality are adequate at final size. For layouts containing text, logos and vector elements, a properly prepared PDF may be more practical.
Final Thoughts
Good exhibition artwork starts with accurate dimensions and a clear production brief. The right file format, appropriate image resolution, correct bleed, safe margins and confirmed colour settings help reduce avoidable corrections and support a smoother print process.
Before sending artwork to production, use the printer's current template and confirm the requirements in writing. A few checks before export can help protect the quality of your exhibition graphics and keep the project moving on schedule.
